Description
Display
Back Light: Direct Type LED
Size (Diagonal): 86″
Resolution: 4K UHD (3840 × 2160)
Brightness: 420 cd/m²
Contrast Ratio: 1,200:1
Contrast Ratio (Dynamic): 4,000:1
Viewing Angle: 178°
Response Time: 6ms
Life: 50,000 Hours
Speaker Count: 2
Watts Per Speaker: 20W
Glass: Toughened, Anti-Glare/Fingerprint
Air Gap: 0.80mm
Touch Resolution: 32,768 × 32,768
Physical Specs
Dimensions (W x D x H): 1957 x 86 x 1160
Wall-Hanging Screw Spec: M8 × 25mm
VESA Holes: 800 × 600
In the Box
Power Cord
USB Cable
HDMI Cable
Remote Control
Writing Pen x 2
Smart Pen Holder
Quick Start Guide
Connections
Inputs:
3 x HDMI
1 x VGA
1 x Audio 3.5mm
1 x S/PDIF
4 x USB 3.0
1 x USB 2.0
2 x RJ45
1 x USB-C
2 x USB Touchport
Outputs:
1 x HDMI
1 x Audio 3.5mm
Control
1 x RS232
WEIGHT
Net Weight: 64.6 kg
Gross Weight: 83 kg
Wireless
Antenna: Optional Accessory
Technology: 802.11ac/b/g/n/a
Operating Frequency: 2.4GHz/5GHz
Touch System
System: Windows 10/Windows 8/Windows 7/Windows XP/Linux/Mac (1 Touch Point Only)/Android/Chrome
Touch Point: Up to 20 Points Touch and 40 Points Touch (Windows)
Touch Tool: Finger, Passive Infra-Red Pen
Power
Power Supply: 100-240V ~ 50/60Hz
Power Consumption (Standby): 0.292W
Power Consumption (Max): 490W
Power Consumption – Average: 162.6W
Operation System
System Version: Android 9.0
CPU: Quad Core A73
GPU: Mali G52
RAM: 4GB
Storage: 32GB
OSD / Display Languages: 16 Languages: Arabic, Czech, Danish, Dutch, English, French, German, Italian, Polish, Portuguese, Russian, Chinese (Simplified), Spanish, Swedish, Chinese (Traditional), Turkish
