Description
Display
| Screen Size | 98″ |
|---|---|
| Panel Technology | IPS |
| Back Light Type | Direct |
| Aspect Ratio | 16:9 |
| Native Resolution | 3,840 x 2,160 (4K UHD) |
| Refresh Rate | 60Hz |
| Brightness | 490 nit (w/o Glass Max.), 390 nit (w/o Glass Typ.), 450 nit (w Glass Max.), 350 nit (w Glass Typ.) |
| Contrast Ratio | 1,200 : 1 |
| Color gamut | NTSC 72% |
| Viewing Angle (H x V) | 178 × 178 |
| Color Depth | 10 bit, 1.07 Billion Colors |
| Response Time | 8 ms (G to G) |
| Surface Treatment (Haze) | Anti Glare, 7 Mohs, Haze 28% |
| Life Time (Min.) | 30,000 Hrs |
| Operation Hours (Hours / Days) | 16 / 7 |
| Portrait / Landscape | No / Yes |
Touch
Touch Type Infrared touch
Touch Accuracy ±1 mm
Response Time (Single Touch) ≤8 ms
Surface Hardness Morse magnitude explosion-proof physical toughened glass
Hit Count Unlimited times
Touch Points 20 points touch
Minimum Identification Diameter 2.5 mm
Hardware parameter
Processor Amlogic-T982 Cortex-A55*4 @ 1.5 GHz
OSD Language English
Operating System Android 11.0
GPU Mali-G52
RAM 8 GB
ROM 128 GB
WiFi 2.4 GHz & 5 GHz + Bluetooth (BT) + AP
Offset port HDMI OUT*1;Touch OUT*1;RJ45 IN*1;RJ45 OUT*1;VGA*1;PC AUDIO IN*1;DP*1;OPTICAL
out*1;LINE OUT*1;HDMI*2;RS232*1;USB Type C*1;USB3.0*2;USB2.0*1
Optional for ops
Processor Intel i5 8th Gen
Operating System Windows 10
RAM 4 GB DDR
Hard Disk 128 GB SSD
WiFi Antenna 2.4 GHz & 5 GHz Dual-Band
Interface USB3.0*4, USB2.0*2,DP*1 HDMI*1, LAN*1, WIFI*2, LINE OUT*1, MIC-IN*1
Eniverment parameters
Working Temperature 0°C to 40°C
Working Humidity 20% to 80% RH
Storage Temperature -10°C to 60°C
Storage Humidity 10% to 90% RH
Altitude Up to 5000 meters
power parameters
Power Source 100-240V ~ 50/60Hz
Power On Consumption ≤550 W
Standby Consumption ≤1 W
Speaker Specification 8Ω / 10W × 2 \
